Category Name : VERTEX TOOL - EDM Wire,VEW-SERIES 維昶VERTEX牌電極線-紅銅,黃銅 Prodouts







ORDER NO.WIRE TYPEDIAMETER(mm)DIAMETER TOLERANCE(mm)BREAKING LOAD(kg)TENSILE STRENGTH(N/mm2)ELONGATION(%)SUITFUL WORKING STYLECODE NO.
Inquriy
VEW-10H
HARD
0.10
±0.001
0.78
980<=
0.4<=
STRIGHT CUTTING a.PASS CUTTING b.ROUGH CUTTING c.FINISH CUTTING
2009-001
 Inquriy
VEW-15H
HARD
0.15
±0.001
1.73
980<=
0.4<=
STRIGHT CUTTING a.PASS CUTTING b.ROUGH CUTTING c.FINISH CUTTING
2009-002
 Inquriy
VEW-20H
HARD
0.20
±0.001
3.14
980<=
0.4<=
STRIGHT CUTTING a.PASS CUTTING b.ROUGH CUTTING c.FINISH CUTTING
2009-003
 Inquriy
VEW-25H
HARD
0.25
±0.001
4.92
980<=
0.4<=
STRIGHT CUTTING a.PASS CUTTING b.ROUGH CUTTING c.FINISH CUTTING
2009-004
 Inquriy
VEW-30H
HARD
0.30
±0.001
7.07
980<=
0.4<=
STRIGHT CUTTING a.PASS CUTTING b.ROUGH CUTTING c.FINISH CUTTING
2009-005
 Inquriy
VEW-30H
HARD
0.33
±0.001
8.55
980<=
0.4<=
STRIGHT CUTTING a.PASS CUTTING b.ROUGH CUTTING c.FINISH CUTTING
2009-006
 Inquriy
VEW-20S
SOFT
0.20
±0.001
1.41
441<=
15<=
ANGLE CUTTING
2009-010
 Inquriy
VEW-25S
SOFT
0.25
±0.001
2.21
441<=
15<=
ANGLE CUTTING
2009-011
 Inquriy
VEW-30S
SOFT
0.30
±0.001
3.18
441<=
15<=
ANGLE CUTTING
2009-012
 Inquriy

"VERTEX TOOL - EDM Wire,VEW-SERIES"

"維昶VERTEX牌電極線-紅銅,黃銅"

FEATURES
CHEMICAL COMPOSITION
  65/35 brass equivalent to Alloy No. JIS-H3260 C2700
NO ACID-CORROSION AND NO DAMAGE TO RESINS
  The special treatment avoids acid-corrosion on machine and work piece.
HIGH SURFACE QUALITY
  The special treatment makes the wire surface smooth,free from dirt,rust and grease that causes unefficiency to electric discharge.
STANDARD WEIGHT CONTROL
  By perfect control in process,we obtain the standard weight per coil that enables us to maintain the stability of processing time and the accuracy of drawing.
NO WELDMENT
  The rough surface caused by welding could affect the quality and accuracy of performance. The welded wire tends to break that wastes the time to re-thread.
HIGH-DIMENSIONAL PRECISION
  Wire diameter tolerance and roundness tolerance are both limited to 1/μ m.
OUTSTANDING STRAIGHTNESS
  Outstanding straightness ensures automatic threading sucessfully.
THE PACKING USED A STANDARD COIL.
HERE SHOW 3 KINDS OF COIL PACKING OF TYPE FOR CHOICE. THE POPULAR IS P-5R(5kgs). OTHER COIL TYPE, WEIGHT. WILL BE AVAILABLE.

PACKING COIL TYPE WEIGHT OF WIRE ON COIL(kg) DIAMETHE OF WIRE(mm) D(mm) d(mm) L(mm) h(mm) LENGTH OF WIRE ON COIL(M) NUMBER OF COILS/BOX CODE NO.
P-3R 3 0.10
0.15
0.20
0.25		 130 80 110 20 39360
18750
10988
6932		 6 2009-021
P-5R 5 0.20
0.25
0.30
0.33		 160 90 114 20 18314
11553
8001
6750		 4 2009-022
K-125 3.5 0.20
0.25		 125 80 125 20 5600
4725		 4 2009-023
K-160 7 0.20
0.25		 160 100 160 22 25640
16174		 2 2009-024
