Category Name : Magnetic Separator & Paper Filter MC+PF-20,40,60,80,120,160 磁鐵+紙帶過濾機 Prodouts







ORDER NO.LABCDEFHWCODE NO.
Inquriy
MC+PF-20
1050
850
600
400
550
665
PF-1-1/2"
610
720
2020-020
 Inquriy
MC+PF-40
1200
1000
600
400
550
705
PF2"
660
720
2020-021
 Inquriy
MC+PF-60
1350
1150
600
400
555
705
PF2"
660
720
2020-022
 Inquriy
MC+PF-80
1500
1300
600
400
555
705
PF2"
660
720
2020-023
 Inquriy
MC+PF-120
1500
1300
800
400
590
705
PF2-1/2"
740
920
2020-024
 Inquriy
MC+PF-160
1800
1600
800
400
605
750
PF3"
740
920
2020-025
 Inquriy
APPLICABLE TO THE FOLLOWING WORKING MACHINES
1. Plane grinding machine.
2. Fine-grinding machine.
3. Honing machine.
4. Deep-hole drill.
5. Internal/exterless cyilnder grinder.
6. Centerless grinder.
● Please specify the power voltage other than 220V/3PH in your order list.
● Specifications are subject to change without ontice.
FEATURES
1. Applicable to both ferrous and non-ferrous metals.
2. Filtration effect depends on paper accuracy.
Use 50μ,30μ, or 15μ.
3. Rough filtration for chip in coolant with magnet and then fine filtration for impurities with paper will save the paper and upgrade filtration accuracy.
DIMENSION DIAGRAM
Remarks
1. Standard accessory: one roll paper 50μ
ORDER NO. DISPOSAL CAPACITY L/MIN WATER TANK CAPACITY PUMP PAPER MOTOR PAPER REMARKS N.W.(kg) G.W.(kg)
HP OUTLET
MC+PF-20 20 100 1/8 PF1/2" 25W W:500MM
L:90MM		 NO wheels 150 140
MC+PF-40 40 120 1/8 PF1/2" 25W 150 175
MC+PF-60 60 140 1/8 PF1/2" 25W 165 200
MC+PF-80 80 160 1/4 PF3/4" 25W 190 225
MC+PF-120 120 210 1/2 PF1/4" 40W W:700MM
L:90MM		 235 275
MC+PF-160 160 260 1/2 PF1/4" 40W 290 335
