Category Name : Boring Head Sets VBH-SERIES 搪孔器組 Prodouts







ORDER NO.TYPEDRAW BARTHREAD METRICWEIGHTCODE NO.
Inquriy
VBH-102
MT3
M12X1.75P
5.9
3401-101
Inquriy
VBH-103
MT4
M16X2.0P
6.1
3401-102
Inquriy
VBH-104
MT5
M20X3.0P
7
3401-103
Inquriy
VBH-105
R8
7/16"-20UNF
5.9
3401-104
Inquriy
VBH-106
NT30
1/2"-12W or 1/2"-13W
M12X1.75P
5.8
3401-105
Inquriy
VBH-107
NT40
5/8"-11W
M16X2.0P
6
3401-106
Inquriy
VBH-108
NT50
1"-8W
M24X3.0P
8.9
3401-107
Inquriy
VBH-109
BT40
-
M16X2.0P
7.1
3401-108
Inquriy
VBH-110
SK40
-
M16X2.0P
6.8
3401-109
Inquriy
VBH-111
C25
-
-
5.9
3401-110
Inquriy
VBH-112
BT50
M24X3.0P
3401-111
Inquriy
1 SCALE  0.01mm
Processing Range  Ø10mm – Ø240mm
Simple, extremely rigid construction, Finest materials and craftsmanship are employed to combine strength, flexibility and accuracy in a tool of unique design. 2 vertical boring tool holes: one centered and one offset. One cross hole for greater versatility and capacity. Dependable adjustment --- far spread graduation for closer reading. Perfectly balanced for high speed operation.
Precision ground & hardened shank are integral with the head for routing and smoother operation.
