Category Name : Quick Change Tapping Chucks 快換攻牙器筒夾 Prodouts







ORDER NO.SIZELD2COLLETWEIGHTCODE NO.
Inquriy
JTA2-SFP12
M8-M12
100
32
TC-820B
0.5
3404-161
Inquriy
JTA6-SFP12
M3-M12
100
32
TC-312B
0.5
3404-160
Inquriy
MT3-SFP20
M8-M20
91
50
TC-820B
1.3
3404-151
Inquriy
MT2-SFP12
M3-M12
65
32
TC-312B
0.4
3404-150
Inquriy
ST20-SF12
M3-M12
100
32
TC-312B
0.3
3404-140
Inquriy
JTA2-SF12
M8-M12
65
32
TC-312B
0.3
3404-131
Inquriy
JTA6-SF12
M3-M12
65
32
TC-312B
0.3
3404-130
Inquriy
MT4-SF33
M14-M33
91
72
TC-1433B
2.2
3404-122
Inquriy
MT3-SF20
M8-M20
61
50
TC-820B
0.8
3404-121
Inquriy
MT2-SF12
M3-M12
44
32
TC-312B
0.3
3404-120
Inquriy

Quick Change Tapping Chucks  快換攻牙器筒夾

l         Torque is factory-set to protect the tap for which a particular collet is designed. Small adjustments can be made by a trained user to accommodate tap strength and material variations.

l         Collet stops driving when set torque is exceeded.

l         A collet is necessary for each tap shank diameter.

l         DIN & ISO systems : please see page 68.
